Simple solar charger circuits are small devices which allow you to charge a battery quickly and cheaply, through solar panels. A simple solar charger circuit must have 3 basic features built-in: It should be low cost. Layman friendly, and easy to build. Must be efficient enough to satisfy the fundamental battery charging needs.
Place the solar panel in sunlight. Check the battery voltage using digital multi meter. Circuit is simple and inexpensive. Circuit uses commonly available components. Zero battery discharge when no sunlight on the solar panel. This circuit is used to charge Lead-Acid or Ni-Cd batteries using solar energy.
Thus this 5V solar battery charger circuit can be considered as an ideal and extremely efficient solar charger circuit for all types of solar battery charging applications. For solar panels with higher voltages, such as 60 V solar panels, the design can upgraded by adding zener diode regulator at pin12 of the TL494, as shown below:
Here is the simple circuit to charge 12V, 1.3Ah rechargeable Lead-acid battery from the solar panel. This solar charger has current and voltage regulation and also has over voltage cut off facilities. This circuit may also be used to charge any battery at constant voltage because output voltage is adjustable.
So, let's dive into the world of renewable energy and learn how to create a solar battery charger! To build the solar battery charger, you must first connect the LM317 voltage regulator IC and the BC547 transistor with the help of resistors and capacitors. Then, connect the LED indicators and the voltage comparators using the LM324 quad op-amp.
As soon as the battery voltage, is under 13.5 volts (usually the open-circuit voltage of a 12 V battery), transistors Q1, Q2, and Q3 switch on and charging current passes through the solar panels as intended. The active green LED shows the battery is getting charged.
